11011143 – Volvo-Style Bolt-On Center Cutting Edge – Fits L30 & L50 Loaders

AU GET supplied by AU Buckets & Equipment

This heavy-duty base edge—also known as a bucket lip or single bevel weld-on edge—features a massive 300mm wide by 32mm thick profile and measures 3200mm in length. Designed to withstand extreme abrasion and impact, this weld-on edge is ideal for new bucket builds, repairs, and heavy-duty earthmoving applications.

Product Specifications:

• Type: Single Bevel Weld-On Base Edge / Bucket Lip

• Dimensions: 300 mm (W) x 32 mm (T) x 3200 mm (L)

• Material: Hardened, wear-resistant alloy steel

• Mounting: Weld-on (solid bar – no holes)

• Hardness: Tested to yield strength between 450–500

Key Features:

• Extra-wide 300mm profile for maximum surface protection

• Single bevel design promotes efficient cutting and clean material flow

• Heavy-duty 32mm thickness for long wear life under harsh conditions

• Ideal for buckets, dozer blades, and custom G.E.T. fabrications

• Compatible with AU Buckets systems and OEM machines

AU GET supplied by AU Buckets & Equipment – engineered to handle Australia’s toughest ground conditions.

AU GET supplied by AU Buckets & Equipment

This Komatsu-style bolt-on center cutting edge is engineered for the WA320 Komatsu Front End Loader. Built from heat-treated, wear-resistant steel, it features a double beveled, reversible design to maximize edge life and cutting performance. With a robust 1.375" thickness, this edge is ideal for demanding earthmoving and loading conditions.

Product Specifications:

• Application: Center Cutting Edge for Komatsu WA320 Loader

• Type: Double Beveled, Reversible

• Thickness: 1.375" (34.93 mm)

• Width: 13" (330.2 mm)

• Length: 60.875" (1546.23 mm)

• Bolt Hole Spacing:

  • 15.1563" (385 mm) center-to-center

  • 7.625" (193.7 mm) from edge to center of the first hole

• Mounting Requirements:

  • (4) Plow Bolts – 1" x 3 1/2" (100 x 350 mm)

  • (4) Hex Nuts – 1" (100 HEX)

• Material: Heat-treated alloy steel

• Hardness: Tested to yield strength between 450–500

Key Features:

• Reversible design provides double the service life

• Double bevel improves cutting efficiency and material flow

• Built to withstand high-impact, abrasive environments

• Precision-drilled holes for quick and secure installation

• Compatible with Komatsu buckets and AU Buckets blade systems

AU GET supplied by AU Buckets & Equipment – built for performance in harsh Australian conditions.

AU GET supplied by AU Buckets & Equipment

This Volvo-style bolt-on center cutting edge is a double bevel, reversible edge designed to fit a range of Volvo loaders. With a heavy-duty profile of 1" thick, 13.78" wide, and 63.94" long, it offers superior wear resistance and cutting performance. Precision-drilled with 11 mounting holes, it ensures a tight, secure fit and is ideal for demanding earthmoving and loading applications.

Product Specifications:

• Type: Double Bevel, Reversible

• Dimensions: 1" (25.4 mm) thick x 13.78" (350 mm) wide x 63.94" (1624 mm) long

• Hole Count: 11

• Bolt Hole Spacing:

  • 4.25" (107.95 mm) center-to-center

  • 4.75" (120.65 mm) from edge to center of first hole

• Mounting Requirements:

  • (11) Plow Bolts – 3/4" x 3" (750 x 300 mm)

  • (11) Hex Nuts – 3/4" (750 HEX)

• Material: Wear-resistant alloy steel

• Hardness: Tested to yield strength between 450–500

Key Features:

• Double bevel for smooth cutting and extended wear life

• Reversible for cost-effective performance

• Precision-drilled for quick and secure installation

• Compatible with Volvo buckets and AU Buckets systems

• Ideal for high-impact construction, quarry, and earthmoving environments

AU GET supplied by AU Buckets & Equipment – tough gear made for Australian worksites.

AU GET supplied by AU Buckets & Equipment

Part T157492 is a John Deere-style bolt-on center cutting edge designed specifically for the 624H John Deere Front End Loader. With a double beveled, reversible design, this edge provides efficient cutting performance and extended wear life for general-purpose loading and material handling.

Product Specifications:

• Application: Center Cutting Edge for John Deere 624H Loader

• Part Number: T157492

• Type: Double Beveled, Reversible

• Thickness: 1" (25.4 mm)

• Width: 10" (254 mm)

• Length: 44.260" (1124.2 mm)

• Bolt Hole Spacing:

  • 14.866" (377.6 mm) center-to-center

  • 7.264" (184.5 mm) from edge to center of first hole

• Mounting Requirements:

  • (3) Plow Bolts – 3/4" x 3" (750 x 300 mm)

  • (3) Hex Nuts – 3/4" (750 HEX)

• Material: Heat-treated, wear-resistant alloy steel

• Hardness: Tested to yield strength between 450–500

Key Features:

• Reversible cutting edge for double the service life

• Beveled on both sides for smooth cutting and reduced resistance

• Precision bolt pattern for secure, vibration-resistant fit

• Fully compatible with John Deere buckets and AU Buckets systems

• Ideal for heavy-duty earthmoving and construction tasks

AU GET supplied by AU Buckets & Equipment – delivering durability and performance in tough Australian environments.

AU GET supplied by AU Buckets & Equipment

This Volvo-style bolt-on end cutting edge is a double beveled, reversible edge designed for the L90 Volvo Front End Loader. With a heavy-duty profile of 1" thick, 15.24" wide, and 24.5" long, this edge offers robust bucket protection and exceptional wear life in demanding loading environments.

Product Specifications:

• Application: End Cutting Edge for Volvo L90 Loader

• Type: Double Beveled, Reversible

• Thickness: 1" (25.4 mm)

• Width: 15.24" (387 mm)

• Length: 24.5" (622.3 mm)

• Bolt Hole Spacing:

  • 4.25" (107.95 mm) center-to-center between first two holes

  • 6.34" (161 mm) from edge to center of first hole

• Mounting Requirements:

  • (8) Plow Bolts – 3/4" x 2.5" (750 x 250 mm)

  • (8) Hex Nuts – 3/4" (750 HEX)

• Material: Heat-treated, wear-resistant steel

• Hardness: Tested to yield strength between 450–500

Key Features:

• Reversible edge for double the service life

• Wide profile for improved corner and sidewall protection

• Designed for fast, secure bolt-on installation

• Compatible with Volvo buckets and AU Buckets blade systems

• Ideal for heavy-duty loading, quarrying, and material handling

AU GET supplied by AU Buckets & Equipment – engineered tough for Australian job sites.

AU GET supplied by AU Buckets & Equipment

This Volvo-style bolt-on end cutting edge is a double beveled, reversible edge designed to suit the Volvo L90 Front End Loader. With a heavy-duty profile of 1" thick, 15.25" wide, and 22.60" long, it delivers maximum edge protection, long wear life, and reliable performance in tough operating conditions.

Product Specifications:

• Application: End Cutting Edge for Volvo L90 Loader

• Type: Double Beveled, Reversible

• Thickness: 1" (25.4 mm)

• Width: 15.25" (387.35 mm)

• Length: 22.60" (574.04 mm)

• Bolt Hole Spacing:

  • 4.45" (113.03 mm) center-to-center

  • 4.49" (114 mm) from edge to center of first hole

• Mounting Requirements:

  • (8) Plow Bolts – 3/4" x 2 1/2" (750 x 250 mm)

  • (8) Hex Nuts – 3/4" (750 HEX)

• Material: Heat-treated alloy steel

• Hardness: Tested to yield strength between 450–500

Key Features:

• Reversible for extended life and cost-effective usage

• Wide coverage area for enhanced corner protection

• Precision-drilled bolt holes ensure secure, vibration-resistant mounting

• Compatible with Volvo buckets and AU Buckets systems

• Ideal for heavy-duty grading, loading, and excavation work

AU GET supplied by AU Buckets & Equipment – built to handle Australia’s toughest job sites.

AU GET supplied by AU Buckets & Equipment

Designed to suit Volvo L60E General Purpose buckets, this bolt-on end blade delivers exceptional durability and side-edge protection in grading and material handling applications. With precisely spaced dual bolt rows, a 0.75" thickness, and 8 pre-drilled holes, this edge is engineered for long service life and easy installation.

Product Specifications:

• Model: Volvo L60

• Series: E

• Configuration: General Purpose

• Blade Position: End

• Thickness: 0.75" (19.05 mm)

• Width: 14.449" (367 mm)

• Length: 21.031" (534 mm)

• Hole Quantity: 8

• Bolt Diameter: 0.625" (5/8")

• Material: Heat-treated alloy steel

• Hardness: Tested to yield strength between 450–500

Hole Spacing – First Row (4 Holes):

• 1st Hole: 3.89" from edge

• 2nd Hole: 4.188" from 1st hole

• 3rd Hole: 4.875" from 2nd hole

Hole Spacing – Second Row (2 Holes):

• 1st Hole: 3.89" from edge

• 2nd Hole: 4.189" from 1st

• 3rd Hole: 4.874" from 2nd

Mounting Requirements:

• Bolts (First Row): 4 x 5/8" x 2.5" (625 x 250 mm) plow bolts

• Bolts (Second Row): 2 x 5/8" x 2.5" (625 x 250 mm) plow bolts

• Nuts: 6 x 5/8" (625 HEX)

Key Features:

• Designed for Volvo L60E general purpose buckets (Serial 80924, 80925)

• Dual bolt row layout for improved stability and retention

• Easy bolt-on replacement with precision hole spacing

• Built for high-wear resistance and long service life

• Fully compatible with AU Buckets systems and OEM Volvo equipment

AU GET supplied by AU Buckets & Equipment – built to perform in tough Australian conditions.
