135-9394 Skid Steer Edge 16mm suits CAT 8 holes 206mm HC, 62.5″ (1588mm)
$200.00 Plus GST
-
Type: Double beveled, reversible bucket center cutting edge
-
Material: High-strength steel for durability and extended wear life
Dimensions:
-
Thickness: 0.625″ (15.88mm)
-
Width: 6.5″ (165.1mm)
-
Length: 62.52″ (1587.95mm)
Mounting Details:
-
Bolt type: 5/8″ x 2″ plow bolt (15.88mm x 50.8mm) (625X200)
-
Nut type: 5/8″ hex nut (625 HEX NUT)
-
Number of bolts and nuts required: 8 each
Bolt Hole Spacing:
-
8.11″ (206mm) center-to-center between the first two bolt holes
-
2.87″ (73mm) from the edge of the cutting edge to the center of the first bolt hole
Compatibility:
-
Designed to fit Case Skid Steer buckets
Features:
-
Reversible design allows for extended wear life
-
Bolt-on installation for easy replacement and maintenance
-
Provides enhanced cutting efficiency for improved skid steer performance
6 in stock
- G.E.T and Accessories (CLICK HERE)
- Description (CLICK HERE)
- Specs/History/Downloads (CLICK HERE)
- G.E.T Product Details
Type: Double beveled, reversible bucket center cutting edge
Material: High-strength steel for durability and extended wear life
Dimensions:
- Thickness: 0.625″ (15.88mm)
- Width: 6.5″ (165.1mm)
- Length: 62.52″ (1587.95mm)
Mounting Details:
- Bolt type: 5/8″ x 2″ plow bolt (15.88mm x 50.8mm) (625X200)
- Nut type: 5/8″ hex nut (625 HEX NUT)
- Number of bolts and nuts required: 8 each
Bolt Hole Spacing:
- 8.11″ (206mm) center-to-center between the first two bolt holes
- 2.87″ (73mm) from the edge of the cutting edge to the center of the first bolt hole
Compatibility:
- Designed to fit Case Skid Steer buckets
Features:
Provides enhanced cutting efficiency for improved skid steer performance
Reversible design allows for extended wear life
Bolt-on installation for easy replacement and maintenance
1359394
